HARDWARE FEATURES |
|
|---|---|
| PROCESSOR | 1.8GHz quad-core CPU and three co-processors |
| STANDARDS AND PROTOCOLS | 802.11a/b/g/n/ac, 802.3ab |
| PORTS | 1x GE WAN 8x GE LAN 2x USB3.0 |
| BUTTON | 1x Power 1x Wi-Fi On/Off 1x WPS 1x Reset 1x LED On/Off |
| LED PANEL | 1x LED with multiple state |
| WEIGHT | 3.3lb(with antennas) 2.65lb(without antennas)1.5kg(with antennas) 1.2kg(without antennas) |
| DIMENSIONS ( W X D X H ) | 11.3 X 11.3X 7.2 in.(with antennas) 9.5X9.5X2.2 in.(without antennas)288X288X184mm(with antennas) 240.6X240.6X55.4mm(without antennas) |
| ANTENNA | 8 external and detachable antennas |
| CHIPSET | MU-MIMO Beamforming Airtime Fairness RangeBoost NitroQAM |
WIRELESS FEATURES |
|
|---|---|
| FREQUENCY | 1000Mbps @ 2.4GHz 2167Mbps @ 5GHz 2167Mbps @ 5GHz |
SOFTWARE FEATURES |
|
|---|---|
| MANAGEMENT | Tether App
Andriod 4.1 or higher |
| SYSTEM TOOLS | Time Settings Diagnostics Fw OTA Upgrade Config backup/resotre Administration Syslog Statistics LED Control |
| BASIC FUNCTION | Network Map(Internet Status/Client List/Speedtest) Internet Settings Wireless Settings USB Sharing Settings(USB Storage Sharing/FTP Server/Print Server/Media Server) HomeCare(Parental Control/Antivirus/QoS) Guest Network Settings TP-Link Cloud Settings Multiple Languages |
| PROTOCOLS | IPv4, IPv6 |
| ADVANCED FUNCTIONS | Working Mode (Router Mode or AP Mode) Wireless Schedule Time Machine TP-Link DDNS Parental Controls/Antivirus/QoS IPv6 VPN Server (OpenVPN and PPTP Servers) NAT Forwarding(DMZ/UPnP…) Link aggregation(WAN/LAN) Airtime Fairness SmartConnect Portal Authentication for Guest Wi-Fi |
SECURITY |
|
|---|---|
| ANTIVIRUS | Malicious Content Filter Intrusion Prevention System Infected Device Quarantine |
| ACCESS CONTROL | Device-based whitelist/blacklist |
| WI-FI SECURITY | Open WEP WPA-PSK |
| FIREWALL FEATURES | Open WEP WPA-PSK |
OTHERS |
|
|---|---|
| CERTIFICATION | FCC、CE、DFS、VCCI、JRF、JPA、RoHS |
| ENVIRONMENT | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| POWER SUPPLY | 100-240V 50/60Hz |
